Puma Destination Trailers

Enjoy vacation comfort in your Puma Destination Model whether for a weekend or a week at the lake, in the mountains, or at your favorite campsite. The best in leisure living with several floorplans; two bedroom options, and a den option to accommodate whatever your family needs are. Residential style furnishings and a large master bedroom with a king size bed to ensure a comfortable and relaxing getaway.

Filter

Select filters below and then click the Filter Results button to remove non-matching Floorplans and their Specifications










to

to




Specifications

Print


Hitch Weight:
GVWR:
UVW:
CCC:
Exterior Length:
Exterior Height:
Exterior Width:
Fresh Water:
Gray Water:
Black Water:
Awning Size:
1780 lb.
11980 lb.
9753 lb.
2227 lb.
40' 6"
11' 9"
96"
51 gal.
35 gal.
35 gal.
19'
1362 lb.
11522 lb.
9748 lb.
1774 lb.
41' 11"
11' 9"
96"
51 gal.
100 gal.
70 gal.
21'
1295 lb.
11500 lb.
9979 lb.
1521 lb.
40' 4"
11' 9"
96"
51 gal.
35 gal.
35 gal.
18'
1525 lb.
11685 lb.
10240 lb.
1445 lb.
41' 8"
11' 9"
96"
51 gal.
70 gal.
35 gal.
19'
1429 lb.
11629 lb.
9468 lb.
2161 lb.
39' 7"
11' 9"
96"
51 gal.
35 gal.
35 gal.
18'
1540 lb.
11700 lb.
10455 lb.
1245 lb.
41' 11"
11' 9"
96"
51 gal.
70 gal.
32 gal.
21'
1392 lb.
11592 lb.
10004 lb.
1588 lb.
40' 6"
11' 9"
96"
51 gal.
65 gal.
35 gal.
21'
1413 lb.
13413 lb.
10709 lb.
2704 lb.
42' 1"
11' 9"
96"
51 gal.
105 gal.
70 gal.
21'

GVWR (Gross Vehicle Weight Rating) – is the maximum permissible weight of the unit when fully loaded. It includes all weights, inclusive of all fluids, cargo, optional equipment and accessories. For safety and product performance do NOT exceed the GVWR.

GAWR (Gross Axle Weight Rating) – is the maximum permissible weight, including cargo, fluids, optional equipment and accessories that can be safely supported by a combination of all axles.

UVW (Unloaded Vehicle Weight)* – is the typical weight of the unit as manufactured at the factory. It includes all weight at the unit’s axle(s) and tongue or pin and LP Gas. The UVW does not include cargo, fresh potable water, additional optional equipment or dealer installed accessories.
*Estimated Average based on standard build optional equipment.

CCC (Cargo Carrying Capacity) ** – is the amount of weight available for fresh potable water, cargo, additional optional equipment and accessories. CCC is equal to GVWR minus UVW. Available CCC should accommodate fresh potable water (8.3 lbs per gallon). Before filling the fresh water tank, empty the black and gray tanks to provide for more cargo capacity.
**Estimated Average based on standard build optional equipment.

Each Palomino RV is weighed at the manufacturing facility prior to shipping. A label identifying the unloaded vehicle weight of the actual unit and the cargo carrying capacity is applied to every Palomino RV prior to leaving our facilities.

The load capacity of your unit is designated by weight, not by volume, so you cannot necessarily use all available space when loading your unit.

Note: Specifications are subject to change without notice.

Features & Options

Print
  • Rubber Roof (12 year warranty)
  • King HD TV Antenna
  • 3/8" Roof Decking
  • 4-1/2" Crowned Truss Roof Rafters
  • Insulated Wrapped Ducted Air Conditioning Runs
  • Molded ABS Fender Skirt
  • Sturdy .024 and .030 Gauge Aluminum Skin
  • Lighted LED Speakers
  • Color Band Metal Enhances Exterior Looks
  • Radius Exterior Doors
  • R-7 Fiberglass Insulation Cut and Glued Between Sidewall Studs
  • Sidewall Studs Spaced 16” Apart
  • Silicone Sealed Radius Compartment Doors
  • Front Diamond Plate
  • Smooth, Aerodynamic Radius Front Metal with Bold Exterior Graphics
  • Molded ABS LP Tank Cover
  • Optional Lighted Power Jack
  • Rugged, Powder Coated Steel I-Beam Frame
  • Floor Ducted Heat
  • Puma Next Generation™ Enclosed and Heated Water Tank
  • Beauflor® Linoleum Flooring with a Seven Year Cold Crack Warranty
  • Longitudinal Floor Studding Spaced 12" Apart
  • 51 Gallon Fresh Water Tank
  • Steel Crossmembers for Added Support
  • Residential Grade Carpet with Pad on Slide Outs
  • 5/8" One-Piece Floor Decking
  • Radius Entry Doors
  • Powder Coated Frames
  • Super Lube Axles
  • Tinted Safety Glass
  • Clamp Ring Windows
  • Double Entry Doors (Where applicable)
  • Pass-Thru Storage (Where applicable)
  • Power Awning with LED Light Strip (Optional on Destination Trailers)
  • EPDM Rubber Roof - 12 Year Manufacturer’s Limited Warranty
  • Four Manual Stabilizer Jacks
  • 9" Three-Tier Steps
  • Rain Gutters with Large Drop Spouts
  • ABS Automotive Style Fender Skirts
  • Radius Baggage Doors
  • Darco Wrapped Underbelly
  • One-piece, 24' Sheet, 5/8" Floor Decking (25 Year manufacturer’s limited warranty)
  • 2" x 3" Flush Joists on 12" Centers
  • Pass-Thru Exterior Baggage Compartments (Where applicable)
  • 2-20 Lb. Gas Bottles
  • 6 Gal. DSI Hot Water Heater
  • Rack & Pinion Electric Slide System with Manual Override (Standard on all slide out models)
  • Clamp Ring Luggage Doors
  • Large Front Pass Thru Baggage Door (TT only)
  • 80" Interior Height
  • Floor Ducted Heat
  • 35,000 BTU Furnace
  • 14" Deep Overhead Cabinets in Super-Slide Models
  • Decorative Kitchen Backsplash
  • Kitchen Ball Bearing Drawer Guides
  • Spice Rack (Kitchen)
  • Divided Silverware Drawer
  • Nickel Finish, Single Control High-rise Kitchen Faucet
  • 3-Burner, High Output Range
  • Stainless Steel Sink
  • Roll-up Stainless Steel Sink Covers
  • Glass Range Cover
  • Built-in Knife Rack
  • LED Ceiling Lights
  • 55 Amp Converter with Battery Charger
  • Bluetooth FM/CD/DVD Stereo
  • Jack Knife Sofa with Pull-down Center Drink Tray – Storage Underneath
  • Jack Knife Sofa Under Bunks
  • Push-back Recliner(s) (Available on Select Models)
  • Wood Medicine Cabinet with Mirrored Door
  • Power Vent in Bath
  • Glass Shower Door (Available on Select Models)
  • 12V Shower LED Light
  • 60” x 80” Queen Beds
  • High Density Foam Mattress
  • Upgraded Soft Teddy Bear Bunk Mats
  • Shirt Closet in Front Bedrooms
  • Nightstands in Front Bedrooms
  • Three Interior Decors
  • Coat Hooks in Entry Way (Most models)
  • Satin Nickel Hardware, Light & Bath Fixtures
  • Radius Dinette Seat Bases
  • Residential Carpet (with pad)
  • Designer Window Treatments (Living room)
  • CO Detector
  • LP Leak Detector
  • Fire Extinguisher
  • Smoke Detector
  • Pre-wired for Solar System
  • Folding Grab Handle
  • Night Shades
  • LED Lighting
  • 13,500 BTU Ducted A/C
  • 16 Cu. Ft. Residential Refrigerator
  • Beauflor® Linoleum
  • Bedspread
  • Bedroom TV Hook-up
  • TV Antenna w/Booster & Cable Hook Up
  • ABS Tub Surround
  • 12 Gal. Gas/Electric DSI Water Heater
  • Bluetooth FM/CD/DVD Stereo
  • Undermount Sink w/Cover
  • Patio Door
  • Four Stabilizer Jacks
  • 30 Lb. Gas Bottles & Cover
  • 50 AMP Service (Second A/C prep)
  • Second A/C 13,500 BTU (Master bedroom)
  • Outside Shower
  • Solid Surface Countertop
  • Upgrade Kitchen Pull-down Faucet
  • Table and Chairs IPO Dinette (Where Available)
  • 12V Ceiling Fan in Living Room
  • Microwave
  • 2 Exterior Speakers
  • 15,000 BTU Ducted A/C IPO 13,500
  • Fireplace with Textured Tile
  • Tri-fold Sofa IPO Jackknife in Living Room
